Water Mist Fire Suppression Systems

Get a Price/Quote

Product Details:

Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Water Mist Fire Suppression Systems Price And Quantity

Minimum Order Quantity 1 Unit

Product Description

Being preferred as the eminent exporters and manufacturers, we are introducing our assortment of Water Mist Fire Suppression Systems. Our range of fire fighting equipments fulfills the general requirements to extinguish fire by producing a fine mist with few residual of water. Further, to maintain the quality standards, we inspect the range the on varied parameters. Customers can avail the Water Mist Fire Suppression Systems from us at highly discounted prices.

Features:

Safe and secure
Easily to carry
Excellent performance

Further Details:

SAFEGUARD TROLLEY MOUNTED WATER MIST CUM CAF FIRE FIGHTING SYSTEM

Technical Data SG01/50

Sr. No.	Technical Particulars
1	Approval	ISO 9001:2008, CE, ERDA
2	Weight of the filled System without Air Bottle	95 Kg. Approx.
3	Weight of the filled Compressed Air Bottle (6l x 200 bar Steel)	11.5 Kg. Approx.
4	Weight of the Gun (Spray & Jet)	2 Kg. Approx.
5	Extinguisher Type	Charged Extinguisher
6	Suitable on Class of Fire	A, B & Live Electrical
7	Functional Temperature Range	+5°C to 60°C
8	Dimension of fire extinguisher (l x w x h)	700 mm x 550 mm x 1200 mm
9	Gun dimension	550 mm x 220 mm
10	Hose length (Std. Type)	5 Mtr.
11	Compressed Air Bottle	6l x 200 bar
12	Operating Pressure	8 to 8.5 bar
13	Range of the Jet	10 - 12 Mtr.
14	Range of the Spray	4 - 5 Mtr.
15	Consumption Rate	0.4L - 0.5L per second
16	Functional Time	95 to 100 Sec.
17	Extinguishing Agent	47 L water + 3L AFFF 6%
